Hot Dawg® Separated Combustion Gas-Fired Unit Heater (HDS/HDC)
Separated Combustion Gas-Fired Unit Heater
The separated combustion Hot Dawg® heater pulls 100% of the combustion air from outside, making this unit ideal for workspaces such as wood shops, garages, and warehouses where the environment can be dusty or dirty. The fresh air supply reduces the common concerns about performance and durability when working in a dusty or particulate-laden environment.
Modine’s separated combustion Hot Dawg® (HDS) is available in 6 model sizes, ranging from 30,000 to 125,000 BTUs. The separated combustion blower models (HDC) are available in sizes ranging from 60,000 to 125,000 BTUs. All models can run on propane or natural gas, depending on your needs.
Certified for residential, commercial, and industrial use.
- Draws combustion air from outside the workspace, ensuring the unit always has plenty of fresh, clean air to breathe.
- Reduces common concerns about dusty, dirty, or humid applications, providing more exceptional durability and reduced maintenance.
- The sealed compartment protects the combustion gas valve, ignition control, manifold, and burners from the environment.
- Factory assembled, certified separated combustion saves installation time.
- Low-profile, lightweight design easily installs 1″ from the ceiling with only two angle brackets*.
- Operates on natural or propane gas; field conversation kits are available.
- Finger-proof fan guards on all units.
- Reduces the need for maintenance with the permanently lubricated motor.
- 100% shut-off with continuous retry to allow for safe ignition in the event the unit doesn’t light on the first try.
- Right or left-hand controls are available on 30-75 BTU Models by rotating the unit 180 degrees.
- The power vented model simplifies side-wall or roof venting with the small-diameter vent pipe.
- Fuel Type: natural or propane gas.
- Designed, Engineered & Assembled in the USA
* Fuel Type: natural or propane gas, field conversation kits are available
Available Models
- HDS: Separated combustion with propeller fan (30,000 to 125,000 BTUs)
- HDC: Separated combustion with blower (60,000 to 125,000 BTUs)
Accessories:
- Concentric and Two-Pipe Vent Kits
- 30, 60, and 90-degree air deflector hoods
- Vibration Isolation Kit
- Summer-Winter Toggle Switch
Documents
6-114 Hot Dawg® Product Sell Sheet
6-584 Hot Dawg® Installation & Service Manual, HDS & HDC
6-175 Hot Dawg® Separated Combustion Unit Heater Catalog
6-549 Power-Vented Unit Heater Troubleshooting Guide
6-120 Competitive Advantage Sound Pressure Data
76-500 Unit Heater Maintenance Checklist
